DRY LINER STG

Thought-out trips.

MANOEUVRABLE DUE TO SELF-STEERING AXLE
SAFE MANOEUVRING WITH REVERSING CAMERA
SUITABLE FOR LONG-TRUCK COMBINATION (TYPE 3)
TYRE CHECK WITH KRONE SMART TPMS

The Dry Liner STG is equipped for all requirements, right up to operation in long-truck combinations. Other ingredients: Trailing steering axle, reversing camera, LED side marker lights with direction indicator flashing function and Krone Smart Tyre Pressure Monitoring System (TPMS).

Technical data

Type

SZK 18 eLB41-STG

King pin load

14000 kg

Axle load

18000 kg

Allowable gross weight

28000 kg

Tare weight

7240 kg

5th wheel height

1180 mm

Axle spread

1810 mm

Internal length

13560 mm

Internal height

2665 mm

Internal width

2480 mm

External width

2550 mm

Always a plus on equipment.

Simply inimitable

Separate underrun protection and lighting support

Underrun protection and lighting supports are mounted in a protected manner and can be replaced individually.

Front wall

The front wall is aerodynamically shaped. The coupling supports provide light and air connections on two levels.

Roller shutter

The rail-compatible roller shutter is space-saving and facilitates handling at the ramp.

Side walls with keyhole plates

In the steel smooth-wall box variant with clinched steel cassettes, the Dry Liner is equipped with keyhole plates as standard. This interior equipment can also be combined with other load securing elements, e.g. double-deck guide rails and / or rod lashing rails.

Kick strip and drainage system

Elevated lateral, double-walled kick strips protect the walls of the superstructure from damage by the forklift or the load. An outflow is incorporated below the keyhole plate to avoid build up of debris.

Front wall protection

The front wall of the Dry Liner is lined on the inside with screen printing plates and thus offers protection against damage.

Flashing side position lamps

Flashing side position lamps are fitted to prevent accidents when turning. It becomes much easier for pedestrians and cyclists to see when the HGV is about to turn.

Premium reversing camera

The premium reversing camera increases safety when manoeuvring and makes the driver's job easier.

Long hgv operation

With its wheelbase and self-steering axle, the two-axle Dry Liner is predestined for use in the long hgv type 3.

DRY LINER: FOUR BASIC VARIANTS

Only KRONE offers dry freight trailers in four basic models: Steel Smooth Body (STG), Plywood Sidewall Body (STP), Plastic Lightweight Sidewall (STK) and SDK LI with light insulation.

DRY LINER: FOUR BASIC VARIANTS

Only KRONE offers dry freight trailers in four basic models: Steel Smooth Body (STG), Plywood Sidewall Body (STP), Plastic Lightweight Sidewall (STK) and SDK LI with light insulation.
